SHIPS FROM MANUFACTURER

HURST R 430 Ram

Call for Pricing

The world’s first triple-stage ram.

We can only sell this product in Illinois. To find your local distributor, go to: https://www.jawsoflife.com/find-a-dealer


Request a Quote SKU: 274070000 Categories: ,
Hurst Jaws Of Life

Description

Capable of carrying out the heaviest rescue operations, this ram is the first of its kind.
Because of its three stages, it delivers a long working range that considerably reduces extrication time. And that saves lives.
It has a push capacity of 30 U.S. tons in the first stage and 14 U.S. tons in the second. Plus, heat-treated claws on the top and base provide grip on flat and angled surfaces. This tool lives up to the “ram” name.
  • Dead man control valve reverts to neutral position if worker’s hand slips from control
  • Dual pilot check valve sustains load requirements if hydraulic flow is interrupted
  • Solid steel piston rod provides high tensile strength and eliminates side-load distortion
  • Heat-treated steel ram feet feature a highly durable gripping surface to minimize slippage
  • Compatible with both HURST High Pressure ram support attachments
TECHNICAL DATA
Length Retracted: 18.7 in / 475 mm
Length Extended: 51 in / 1295 mm
Width: 4.41 in / 112 mm
Depth: 8.7 in / 221 mm
Weight: 39 lbs / 17.7 kg
Stroke – Piston 1: 11.61 in / 295 mm
Stroke – Piston 2: 11 in / 280 mm
Stroke – Piston 3: 9.65 in / 245 mm
Stroke – Overall: 32.3 in / 820 mm
Max Pushing Force – Piston 1: 60,474 lbs / 269 kN
Max Pushing Force – Piston 2: 30,124 lbs / 134 kN
Max Pushing Force – Piston 3: 8,768 lbs / 39 kN
NFPA 1936 2020 Compliant: Yes
